Full Description
A huge number of guitars come equipped with standard humbuckers, but the fun doesn’t have to stop there. Using a humbucker-sized P90 can offer a wider, more open sound, and open up new musical avenues.
Powered by twin Alnico 2 bar magnets, and with a strong bass and crisp highs, the Rebel 90 finds the sweet spot between single coil and humbucker tonalities.
Nickel Silver Covers on all models. #3-48 screws and springs supplied and a full installation guide supplied.
Neck 7.6k / Bridge 7.9k, Alnico 2
Tech Specs
| Rebel 90 Neck | Rebel 90 Bridge | ||
|---|---|---|---|
| Model | R90V-N | R90V-B | |
| Magnet | Twin Alnico 2 Bar | Twin Alnico 2 Bar | |
| DCR | 7.6k | 7.9k | |
| Inductance | 3.4H | 4.2H | |
| Hookup Wire | 2-Conductor | 2-Conductor | |
| Winding Direction | Counter-Clockwise | Clockwise | |
| Polarity | South Pole Up | North Pole Up |
Dimensions
Full Description
A huge number of guitars come equipped with standard humbuckers, but the fun doesn’t have to stop there. Using a humbucker-sized P90 can offer a wider, more open sound, and open up new musical avenues.
Powered by twin Alnico 2 bar magnets, and with a strong bass and crisp highs, the Rebel 90 finds the sweet spot between single coil and humbucker tonalities.
Nickel Silver Covers on all models. #3-48 screws and springs supplied and a full installation guide supplied.
Neck 7.6k / Bridge 7.9k, Alnico 2
Tech Specs
| Rebel 90 Neck | Rebel 90 Bridge | ||
|---|---|---|---|
| Model | R90V-N | R90V-B | |
| Magnet | Twin Alnico 2 Bar | Twin Alnico 2 Bar | |
| DCR | 7.6k | 7.9k | |
| Inductance | 3.4H | 4.2H | |
| Hookup Wire | 2-Conductor | 2-Conductor | |
| Winding Direction | Counter-Clockwise | Clockwise | |
| Polarity | South Pole Up | North Pole Up |
Dimensions
Installation & Wiring Diagrams
Media
I love P90s, especially in the neck position. I hope Tonerider develops more Humbucker sized P90s, maybe with Alnico 4 for neck/bridge and a Alnico 5 for Bridge.
Put a pair of these in an Epiphone SG, very happy with the sound, look and quality of these pickups.
Excellent pickups
I play heavy metal and the sound with these pickups is warmer than ever.
Thumbs Up!!
Had a lot of interest in these pick ups and for the money they are a great upgrade and sound great.
